Description
STYLE
KLC-UT75
VESA
200x200~600x400mm
Fits
55-75inches
Tilt
±5°
Swivel
-60°/+60°
Load Capacity
40KGS(88lbs)
Distance to wall
30-363mm
Heavy duty construction.
With this full-motion mount, you can be easy to fix, tilt, extend, fold and rotate your TV and any viewing angle whatever you wanted.
The wall plate cover and cable hidden system looked more luxury and nice, also made the TV cable behind your TV neatly.
Standard installation hardware screws included.
Fit: 55-75inches
VESA: 200x200~600x400mm
Distance to the wall: 30-363mm
Tilt: ±5°
Horizontal: ±2°
Max load capacity: 40KGS(88lbs)
Material: SPCC, Seamless Steel Tube and Plastic.
VESA: When we refer to VESA sizes we are referring to the standard used to measure the hole pattern on the back of your Display. If you do know your VESA pattern you can simply measure the distance side to side and top to bottom on your display. The distance in millimeters is the Vesa Hole Pattern.
